Colibri Manual Ver. 4.2 Dec 2006
LX Navigation d.o.o. www.lxnavigation.si
20
DURATION: Duration of the flight, from take off until landing
DATE: Date of flight
TASK STAT.: Task statistics available after pressing Enter
Note!
Task statistics are available only if a task was declared. If the task was modified during flight, the statistics
data will be based on the declared task and not on the real flown task and will be therefore be wrong.
After pressing Enter on TASK STAT, there will be delay of some seconds while the unit makes a
calculation before displaying:
Tsk.dist: Task distance
FINISHED: Confirms a correctly flown task with no missing points
V: Average speed on task
NoFINISH: Indicates that there is a problem with the task; some turn points or finish are missing
Vario: Vario average and percentage of time spent climbing
Track d.: Actual distance flown
4 Wiring and installation
As previously mentioned, the unit is very small is capable of being installed in many places in the glider. When
deciding on where to install it, one factor is whether or not the unit will be used in flight to display navigational
data. If so, then a position is required whereby it is easy to see the screen and manipulate the buttons during
flight. The unit is supplied with a dedicated mounting bracket that enables it to be easily removed when
required.
4.1 Wiring
All necessary cables and leads (other than a USB cable) are supplied with the unit.
Power supply cable (red +ve, blue -ve)
Power and data cable for connecting external devices such as a PDA or LX 7000…
PC cable with AC/DC power supply for PC communication
USB mini B to USB cable, if USB port will be used for PC communication (not delivery included)
The table below shows the cabling requirements for connection to other devices. When used with the LX
7000/LX 7007, LX 160si and LX 1600, the vario automatically powers the Colibri.
Colibri/LX20-2000
P.and data cable
232 cross LXIPQ
adapter
Cable delivered
with LX unit
LX 160 X X
LX 160 si X
LX 1600 X
LX 5000 X X
LX 7000 X
PDA X
