3. Technical data
3.1. Technical data of SmartControl
SC5-R-E-A
SC5-R-E-A- ENC
SC5-G-E-A
SC5-G-E-A-ENC
SC5-R-E-M
SC5-R-E-M-ENC
SC5-G-E-M
SC5-G-E-M-ENC
SC5-R-E-W
SC5-R-E-W-ENC
SC5-G-E-W
SC5-G-E-W-ENC
SC5-R-N-M
SC5-R-N-M-ENC
SC5-G-N-M
SC5-G-N-M-ENC
SC5-R-N-W
SC5-R-N-W-ENC
SC5-G-N-W
SC5-G-N-W-ENC
Rated Power Voltage 24V DC
Allowable Voltage Range 10 do 40V DC
Maximum Input Current 100mA (10V DC) 60mA (24V DC)
Maximum Power
Consumption
1,5 W ( 24V DC )
Allowable Momentary
Power Interruption
10ms ( przy 24V DC )
Dielectric Strength 1000V AC, 1 minute
Insulation Resistance Minimum 10MΩ
Inrush Current Maximum 10A (24V DC)
Power Supply Wire AWG26 – AWG24 0,14mm² – 0,5mm²
Operating Temperature 5 do 40°C
Storage Temperature -40 do +70°C
Relative Humidity 10 do 95% (IEC61131-2) no condensation
Altitude 0 do 2000m
Pollution Degree 3
Degree of Protection IP65 (IEC60529)
Signal Wire AWG26 – AWG24 0,14mm² – 0,5mm²
Vibration Resistance 5 do 8,4Hz - amplitude 3,5mm , 8,4 do 150Hz acceleration 1G (IEC61131-2)
Shock Resistance 15G, 11ms, a half of sinusoid, in each of three perpendicular axes
Interfaces 1 – RS232 2 - RS485/422/485 4W
Communications protocols
BALDOR HCP1 (MASTER)
BALDOR HCP2 (MASTER)
FATEK PROTOCOL
MODBUS RTU (MASTER)
MODBUS RTU (SLAVE)
Chosen protocol on request
Transmission speed
(baud)
19200, 38400, 57600, 115200
Display 4 x 16 characters, blue background, white characters
Number of screen pages 4096
Number of texts 2048 x 4 languages
Number of variables per
page
max 64
Weight (without cord) 530g 550g 525g 545g 520g
Weight (without cord)
Hand wheel version (ENC)
