3.8. Technical data of automatic work mode switch SC5-AUT
SC5-AUT
Automatic work mode
switch (IDEC) – catalog
no. of the manufacturer
HS5D-12RNM
Applicable Standards
ISO14119
EN1088
IEC60947-5-1
EN60947-5-1
GS-ET-15 UL508
CSA C22.2 No. 14,
GB14048.5
Applicable Standards for
Use
ISO 12100 / EN292
IEC 60204-1 / EN 60204-1
ISO 13849-1
EN954-1
IEC 61508
Operating Temperature -30 do +70
Storage Temperature -40 do +80
Relative Humidity 45 do 85% ( no condensation )
Rated Insulation Voltage 300V
Degree of Protection IP67 (IEC60529)
Actuator Operating Speed 0,05 do 1,0 m/s
Direct Opening Travel 10mm minimum
Direct Opening Force 50N minimum
Termal Current 10A
Contacts 2NC – 1NO
Strand transverse section 20 do 16 AWG 0,5 do 1 mm²
Rated Voltage
Contact
Ratings
Rated
Voltage
Contact
Ratings
AC AC
AC
DC DC
Contact Ratings
DC
Minimum Applicable Load 5V AC/DC, 1mA
Operating Frequency 900 / hour
Mechanical Durability 1000 000 operations minimum
Electrical Durability
100 000 operations minimum ( AC-12 250V, 6A )
1000 000 operations minimum ( 24V AC/DC, 100mA )
( with frequency of operations of 900/ hour)
Cable diameter 7 – 13mm
Cable gland
Size of installation wrench 25mm
Weight about 80g
