3.7. Technical data of SC5-CAB cables
SC5-CAB-N-AAA SC5-CAB-S-AAA SC5-CAB-D-AAA-BBB
Type of cable LiYCY-P 12 x 2 x 0,14 mm²
Strand transverse section AWG26 0,14mm²
External diameter 8,5mm
Shield YES
Wire resistance 0,276 Ω / m ( for one loop ) max
Resistance for oil, grease
Resistant with sporadic contact
Condition of cable end
from SmartControl
Cable installed and connected to SmartControl according to the schematic in the instruction
manual
Cable splitting NO NIE
Cable split in two parts with
AAA and BBB lenghts:
The first part connected to
SmartControl from one side,
from the other to the D-SUB
hermetic connector.
The second part of the cable
ended with D-SUB hermetic
seal for installation in the
switch cabinet from one side,
and from the other with 26 pin
plug for SC5-INT distributor
Cable enables easily
disconnection of SmartControl
from the machine ( e.g. for
transport )
Condition of cable end
from SmartControl
Cable ended with free wires of
20 cm length
Cable ended with 26 pin plug
adjusted to SC5-INT
distributor
Cable ends with 26 pin plug
adjusted to SC5-INT
distributor
Cable gland SKINTOP M20x1.5 Black with cap. Installed on the cable
None, the function of gland is
performed by D-SUB hermetic
seal
Weight about 90g / m
