4.3. Connection of automatic machine work mode switch SC5-AUT
4.3.1 SC5-AUT connection pattern
4.3.2 Example of safety system with automatic work mode switch
SC5
-
G
-
E
-
A
Example 1
Power supply
of machine
drives
Main Power
supply of
machine
SC5
-
R
-
E
-
A
Example 2
WARNING: SC5-AUTswitch must be fixed outside the danger zone!
Power supply
of machine
drives
