MacDon M155 - Page 24

147762 18 Revision C
1013950
A
Figure 3.27: C3B Connector with Terminal Lock
in Place
9. Reinstall the terminal lock (A).
1013949
Figure 3.28: Harness Connected to C3B
10. Couple the connector.
1013917
A
Figure 3.29: Air Filter Pan and Filter
11. Replace the fresh air filter pan (A) and filter.
INSTALLATION INSTRUCTIONS
