Mackie TT24 Digital Live Console Quickstart Guide TT24 Specifications
29
Output Impedance
L/R/C-Mono, Group/Matrix Out 150 Ω
Aux Send, Monitor Out 150 Ω
CD/Tape A and B Out 600 Ω
Maximum Output Level
Insert Out +22 dBu
L/R/C-Mono, Group/Matrix Out +26 dBu
Aux Send, Monitor Out +21 dBu
CD/Tape A and B Out +22 dBu
Phones Out 500 mW into 100 Ω
System
Frequency Response (Gain at unity)
Mic Input to Main Output
+0, –1 dB, 10 Hz to 20 kHz @ 44.1 kHz
+0, –2 dB, 10 Hz to 40 kHz @ 96 kHz
+0, –0.5 dB, 14 Hz to 27.5 kHz @ 96 kHz
Distortion (THD + N)
Mic Input to Main Output
< 0.02% @ +4 dBu input, 44.1 kHz, 10 Hz to 20 kHz
< 0.03% @ +4 dBu input, 96 kHz, 10 Hz to 20 kHz
AES Input with SRC to AES Output
< 0.0002% @ –10 dBFS input, 44.1 kHz, 10 Hz to 22.05 kHz
< 0.0006% @ –10 dBFS input, 96 kHz, 10 Hz to 48 kHz
Signal to Noise Ratio –78 dBu (ref. +4 dBu Mic In to Main Out)
Dynamic Range 101 dB (Mic In to Main Out)
Maximum Voltage Gain 96 dB (Mic In to Main Out)
Crosstalk
Adjacent Inputs –110 dB @ 1 kHz
Adjacent Main Outputs –95 dB @ 1 kHz
Adjacent Aux Outputs –115 dB @ 1 kHz
