FUNCTION PARAMETER VALUE RANGE/INCREMENTS DEFAULT VALUE
Reverb Through Gate
Size 3–40 m (1 m steps) 10 m
Decay 0.1–10 s (0.1 s steps) 1.6 s
Pre Delay 0–300 ms (1 ms steps) 0 ms
Diffusion 0–10 (1 steps) 5
Damping 0–10 (1 steps) 5
Roll Off Flat to 500 Hz (scaled steps) Flat
Threshold –60 dBFS to –1 dBFS (0.2 dBFS steps) –60 dBFS
Release 10–2500 ms (scaled steps) 100 ms
Hold 0–2500 ms (scaled steps) 0 ms
EQ On/Off On/Off Off
Low Shelf Gain –15 dB to +15 dB (0.1 dB steps) 0 dB
Mid Gain –15 dB to +15 dB (0.1 dB steps) 0 dB
Mid Frequency 20 Hz – 20 kHz (scaled steps) 2 kHz
Mid Bandwidth 2 octaves to 1/30 octave (scaled steps) 1/2
High Shelf Gain –15 dB to +15 dB (0.1 dB steps) 0 dB
Mono Delay
Delay 0–1600 ms (scaled steps) 250 ms
Feedback 0% to 100% (1% steps) 20%
Damping Flat to 500 Hz (scaled steps) Flat
EQ On/Off On/Off Off
Low Shelf Gain –15 dB to +15 dB (0.1 dB steps) 0 dB
Mid Gain –15 dB to +15 dB (0.1 dB steps) 0 dB
Mid Frequency 20 Hz – 20 kHz (scaled steps) 2 kHz
Mid Bandwidth 2 octaves to 1/30 octave (scaled steps) 1/2
High Shelf Gain –15 dB to +15 dB (0.1 dB steps) 0 dB
Stereo Delay
Delay Left 0–1600 ms (scaled steps) 250 ms
Delay Right 0 –1600 ms (scaled steps) 250 ms
Feedback Left 0% to 100% (1% steps) 20%
Feedback Right 0% to 100% (1% steps) 0.2
Damping Left Flat to 500 Hz (scaled steps) Flat
Damping Right Flat to 500 Hz (scaled steps) Flat
EQ On/Off On/Off Off
Low Shelf Gain –15 dB to +15 dB (0.1 dB steps) 0 dB
Mid Gain –15 dB to +15 dB (0.1 dB steps) 0 dB
Mid Frequency 20 Hz – 20 kHz (scaled steps) 2 kHz
Mid Bandwidth 2 octaves to 1/30 octave (scaled steps) 1/2
High Shelf Gain –15 dB to +15 dB (0.1 dB steps) 0 dB
