55
Owner’s Manual
Owner’s Manual
SIGNAL TO NOISE RATIO
–78 dBu (ref. +4 dBu Mic In to Main Out)
DYNAMIC RANGE
101 dB (Mic In to Main Out)
MAXIMUM VOLTAGE GAIN
96 dB (Mic In to Main Out)
CROSSTALK
Adjacent Inputs –110 dB @ 1 kHz
Adjacent Main Outputs –95 dB @ 1 kHz
Adjacent Aux Outputs –115 dB @ 1 kHz
DIGITAL
FADERS
Type 100 mm motorized, movement sensitive
Resolution 128 steps
SAMPLING FREQUENCY
44.1, 48, 88.2, 96 kHz (Internal and External)
DIGITAL SIGNAL PROCESSIN
32-bit floating point resolution
PROPOGATION DELAY (Mic In to Main Out)
< 3.8 ms @ 44.1 kHz
< 1.7 ms @ 96 kHz
Minimum Level 0.4 V p-p
Duty Cycle 50%
Impedance 75 Ω
External Word Clock Lock Range 44.1 kHz = 42.5 kHz – 45.8 kHz
48 kHz = 46.4 kHz – 49.4 kHz
88.2 kHz = 85.0 kHz – 90.7 kHz
96 kHz = 92.2 kHz – 98.2 kHz
WORD CLOCK OUTPUT
Open Circuit Level 5 V p-p
Duty Cycle 50%
Impedance 75 Ω
AES INPUT (IEC-60958-3)
Sample Rate with SRC 32 kHz – 96 kHz
Sample Rate without SRC System sample rate exactly
Maximum Level 0.4 V p-p
Impedance 110 Ω, transformer coupled
AES OUTPUT (IEC-60958-3)
Sample Rate System rate or switchable half system rate
Level into 110 Ω 5 V p-p
Impedance 110 Ω, transformer coupled
S/PDIF INPUT
Sample Rate with SRC 32 kHz – 96 kHz
Sample Rate without SRC System sample rate exactly
Minimum Level 0.4 V p-p
Impedance 75 Ω
S/PDIF OUTPUT
Sample Rate System rate or switchable half system rate
Level into 75 Ω 0.5 V p-p
Impedance 75 Ω, transformer coupled
