TYRES
Note: When refitting, tighten to 100 Nm.
18. Remove both rear wheel securing plate bolts (T50 Torx™).
Note: Left-hand shown, right-hand similar.
Note: When refitting, tighten to 35 Nm.
19. Remove the 3 bolts (T30 Torx™) securing the electric motor
control module cover
Note: When refitting, tighten to 8 Nm.
20. Carefully reposition and support the electric motor control
module cover.
NOTICE: Make sure wiring harnesses or components attached
to the electric motor control module cover are not trapped or
damaged while removing the rear wheel and motor assembly.
! ! !
! ! !
! ! !
! ! !
!
