MAINTENANCE WORK
ELECTRICAL SYSTEM
Maintenance manual T225/T230 99
Fuses
The electrical consumers are protected by fuses with the
appropriate amperage.
Therefore you may never bypass a defective fuse or replace it
with a fuse with a higher current.
Fig. 71: Central electric box
The electrical fuses for the vehicle are located on the right side
of the operator in a fuse box.
Fig. 72: Main fuse
In addition to the individual vehicle fuses, there is a main fuse.
It is located in the battery compartment.
