MAINTENANCE WORK
LUBRICATING POINTS
Maintenance manual T225/T230 39
Lubricating points Fig. pos. no. Number
Fifth wheel / fifth wheel coupling
Saddle plate 9-1 2
Hydraulic cylinder swivel bearing 9-1 2
Fifth wheel friction bearing brush 9-1 2
Lug eyes of hydraulic cylinder 9-2 2
Axles
Top steering knuckle connection 11-1 2x1
Bottom steering knuckle connection 11-3 2x1
Axle suspension
Front bearing of front axle 10-1 2x1
Rear bearing of front axle 10-2 2x2
Bearing of rear axle 10-3 2x1
Driver's cab
Top hinge of driver's door 12-1 1
Bottom hinge of driver's door 12-1 1
Brake
Linkage adjuster (front axle) 11-1 2x1
Brake camshaft bearings (front axle) 11-1 2x1
Brake shoe bearings (front axle) 11-2 2x2
