MAINTENANCE WORK
MOTOR
Maintenance manual T225/T230 51
Checking and refilling motor oil level
The oil dip stick and the oil filter nozzle are located in the
maintenance opening, behind the driver's cab.
Fig. 22: Maintenance opening, engine
CAUTION!
Engine damage!
A too-high or too-low oil level can damage the engine.
X Make sure that the oil level never goes beyond the
“MAX” or “MIN” limits.
X Use only authorised types of oil.
Only check the oil level when the motor is at operating
temperature and not running. Make sure the MT is
parked on level ground.
Fig. 23: Oil dip stick and oil filler neck
1 Oil filler nozzle
2 Oil dip stick
X
Pull out the oil dip stick 2.
X Wipe the oil dip stick 2 with a clean, lint-free cloth.
X Reinsert the oil dip stick 2 completely.
X Pull the oil dip stick 2 out again.
The oil level should lie between the “MIN” and “MAX”
markings.
X Refill oil into the oil filler nozzle 1 if necessary.
