MAINTENANCE WORK
AIR CONDITIONER
94 Maintenance manual T225/T230
Air filter element for fresh air and circulation
The air filter element for the fresh air and circulation supply is
installed in the housing of the heater/air conditioning, and
accessible via the air grate on the front side of the MT.
Fig. 64: Fresh circulation filter
1 Air grate
2 Air filter element
X
Screw off the air grate and remove the air filter element.
The air filter element can be taken out from above through
the shaft.
X Check the air filter element for soiling and replace if
necessary.
X Install the air filter element while making sure it is positioned
properly, and screw in the air grate.
