10 | PGM Programming
MG6250 • Section Programming Guide
PGM Programming
PGM Serial Number
Activation/Deactivation Event Settings
PGM Options
PGM Delay
PGM Label
Section PGM PGM Serial Number
[0301] 1 / / / / /
[0302] 2 / / / / /
[0303] 3 / / / / /
[0304] 4 / / / / /
[0305] 5 / / / / /
[0306] 6 / / / / /
[0307] 7 / / / / /
[0308] 8 / / / / /
Section Description Event Group Sub-group
Partition
(3 for both)
Default
[0321] PGM1 Activation/Deactivation Event / / / 00/00/0
[0322] PGM2 Activation/Deactivation Event / / / 00/00/0
[0323] PGM3 Activation/Deactivation Event / / / 00/00/0
[0324] PGM4 Activation/Deactivation Event / / / 00/00/0
[0325] PGM5 Activation/Deactivation Event / / / 00/00/0
[0326] PGM6 Activation/Deactivation Event / / / 00/00/0
[0327] PGM7 Activation/Deactivation Event / / / 00/00/0
[0328] PGM8 Activation/Deactivation Event / / / 00/00/0
Option Description
PGM 1 [0341] PGM 2 [0342] PGM 3 [0343] PGM 4 [0344] PGM 5 [0345] PGM 6 [0346] PGM 7 [0347] PGM 8 [0348]
OFF ON OFF ON OFF ON OFF ON OFF ON OFF ON OFF ON OFF ON
1 PGM time base (OFF=Sec, ON=Min)                
2 Console supervision                
3 Wireless PGM supervision                
4 Voice control                
5
Remote output time base
(OFF=Sec, ON=Min)
               
6Future use ----------------
7Future use ----------------
8Future use ----------------
Section PGM PGM Delay Value Default
[0361] PGM1 / / (001 to 255 x 1 sec./min.) 005
[0362] PGM2 / / (001 to 255 x 1 sec./min.) 005
[0363] PGM3 / / (001 to 255 x 1 sec./min.) 005
[0364] PGM4 / / (001 to 255 x 1 sec./min.) 005
[0365] PGM5 / / (001 to 255 x 1 sec./min.) 000
[0366] PGM6 / / (001 to 255 x 1 sec./min.) 000
[0367] PGM7 / / (001 to 255 x 1 sec./min.) 005
[0368] PGM8 / / (001 to 255 x 1 sec./min.) 005
Section PGM PGM Label
[0381] 1 / / / / / / / / / / / / / / /
[0382] 2 / / / / / / / / / / / / / / /
[0383] 3 / / / / / / / / / / / / / / /
[0384] 4 / / / / / / / / / / / / / / /
[0385] 5 / / / / / / / / / / / / / / /
[0386] 6 / / / / / / / / / / / / / / /
[0387] 7 / / / / / / / / / / / / / / /
[0388] 8 / / / / / / / / / / / / / / /
