6 | Zone Programming
MG6250 • Section Programming Guide
Zone Programming
NOTE: If a device is assigned to a zone which is already programmed, a wireless zone will overwrite a hardwire zone.
Zone Definition Values
To program zone definitions and assign options:
1. Press and hold 0.
2. Enter your installer code or maintenance code.
3. Enter the four-digit zone you wish to program.
4. Enter the two-digit zone definition, refer to table 4.
5. Assign the partition, refer to table 5. By default, all zones are assigned to partition 1.
6. Select or de-select zone options using buttons 1 through 8, see table 6 or table 7.
7. Press the # key to save and proceed to the next zone. Repeat steps 3 to 6 for all remaining zones.
Table 4: Zone definitions
Input
Value
Description
Arming Type
OFF Stay Arm Sleep Arm Full Arm
00 Disabled (default)
----
01 Entry delay 1*
Not armed Entry delay 1 Entry delay 1 Entry delay 1
02 Entry delay 2*
Not armed Entry delay 2 Entry delay 2 Entry delay 2
03 Entry delay 1 (full arm)
Not armed Not armed Not armed Entry delay 1
04 Entry delay 2 (full arm)
Not armed Not armed Not armed Entry delay 2
05 Follow*
Not armed Follow Follow Follow
06 Follow (sleep/full arm)
Not armed Not armed Follow Follow
07 Follow (full arm)
Not armed Not armed Not armed Follow
08 Instant*
Not armed Instant Instant Instant
09 Instant (sleep/full arm)
Not armed Not armed Instant Instant
10 Instant (full arm)
Not armed Not armed Not armed Instant
11 Instant fire*
----
12 Delayed fire*
----
13 Instant fire silent*
----
14 Delayed fire silent*
----
15 24 hr. buzzer*
----
16 24 hr. burglary*
----
17 24 hr. hold-up*
----
18 24 hr. gas*
----
19 24 hr. heat*
----
20 24 hr. water*
----
21 24 hr. freeze*
----
22 24 hr. panic*
----
23 Follow no pre-alarm*
Not armed - - -
24 Instant no pre-alarm*
Not armed - - -
25 Keyswitch maintain*
----
26 Keyswitch momentary*
----
27 Delay 1 (sleep/full arm)
Not armed Not armed Entry delay 1 Entry delay 1
28 Delay 2 (sleep/full arm)
Not armed Not armed Entry delay 2 Entry delay 2
29 Unarmed*
Not armed Not armed Not armed Not armed
30-32 Future use
----
33 Custom template 1†
Not armed Instant Instant Not armed
34 Custom template 2†
Not armed Not armed Instant Not armed
35 Custom template 3
Not armed Entry delay 1 Instant Entry delay 1
36 Custom template 4
Not armed Instant Instant Entry delay 1
*: Zone definitions that can be used in custom zone templates.
-: Zone definitions remain the same, regardless of arming type.
†: WARNING: Do not use these denitions for a common zone. The denition of a common zone follows the denition relative to the
area that gets the lowest level of arming. A problem may occur if a common zone follows an area armed in Stay/Sleep and an area
armed in Full. The resulting zone definition will be the one relative to the lowest level of arming which is Stay armed. The zone will
be considered as armed in both areas.
Table 5: Partition assignment
Partition assignment
Input
Value
Description
1 Assign to partition 1
2 Assign to partition 2
3 Assign to both partitions
Table 6: Zone options
Zone options
Input
Value
Description
1Auto zone shutdown
2 Bypassable zone
3 RF zone supervision
6 Intellizone delay
7 Delay arm transmission
8Force arming
Input Value
Zone Alarm Type
4 5
OFF OFF Audible alarm
ON OFF Silent alarm
OFF ON Audible pulse
ON ON Report only
Table 7: Keyswitch options
Keyswitch options
Input Value
Levels of Arming
1 2
OFF OFF Disarm
ON OFF Stay Arm
OFF ON Sleep Arm
ON ON Full Arm
Input Value Description
3-
4 Disarm partial arm only
5Arm only
6-
