7 Troubleshooting
MAGNETEK HPV1000 AC Elevator Drive Technical Manual 59
oPE07
Analog Setup Alm
A contradictory setting is assigned to
multi-function analog inputs.
At least two analog input terminals are set to the same function.
oPE08
Mode Setting Alm
A function has been set that cannot be
used in the motor control method
selected.
Attempted to use a function that is not valid for the selected control mode.
Note: Use oPE Flt Parameter (F2) to find which parameter is
causing the oPE08 to be declared. Other errors are given
precedence over oPE08 when multiple errors occur
simultaneously.
Incorrect selection for Control Method (U8)
• Check the selected control mode in the U8 sub-menu.
oPE10
V/F Setup Alm
The following setting errors have
occurred where:
Correct the settings for VF pattern in the A5 menu.
oPE16
EnrgSavSetup Alm
Energy Savings Constants Error Energy saving coefficients are out of the allowable range.
oPE18
ParamSetting Alm
Parameter Setting Error:
A configuration relating to load cell
inputs is incorrect. This is a non-standard
feature, contact Magnetek for further
assistance.
Multiple parameters relating to load cell inputs have the same setting. This is
a non-standard feature, contact Magnetek for assistance.
oPE20
PPR setting Alm
The encoder signal frequency is too high.
With the entered Encoder Pulses (A1), Rated Motor Freq (A5) and Number
Of Poles (A5), the calculation encoder signal frequency exceeds 50 kHz (with
PG-F3 option) or 20 kHz (with PG-E3 option).
• Set Encoder Pulses (A1) to the correct encoder resolution.
• Reduce the maximum output frequency of the drive in parameter Rated
Motor Freq (A5) so the encoder signal frequency at maximum speed is
lower than 50 kHz.
oPE21
Start Setup Alm
Elevator parameters are not set correctly.
The DC Brk Time Stop (A1) is set to a value lower than the Brake Close
Delay A1.
• Correct parameter settings.
oPr
Oper Disconnect
Operator Con Alm
The external operator has been
disconnected from the drive.
Note: An oPr fault will occur
when all of the
following conditions
are true:
• Output is interrupted when the operator
is disconnected.
External operator is not properly connected to the drive.
• Check the connection between the operator and the drive.
• Replace the cable if damaged.
• Turn off the drive input power and disconnect the operator. Then reconnect
the operator and turn the drive input power back on.
oS
Overspeed Flt
Overspeed Alm
The motor speed feedback exceeded the
Overspd Det Lvl (A1).
Overshoot is occurring.
• If using a closed loop vector mode, increase Inertia (A1).
Inappropriate parameter settings.
• Check the setting for the Oversp Det Lvl (A1) and Overspd Det Time (A1).
Fault Code/Name Description Causes and Solutions
