Magnetek Elevator HPV1000 AC - EMC Filters, Fuses and Dynamic Braking Resistors; Drive Derating Data

8 Appendix
MAGNETEK HPV1000 AC Elevator Drive Technical Manual 71
 EMC Filters, Fuses and Dynamic Braking Resistors
Use the EMC filters, fuses and dynamic braking resistors listed in the table below.
 Drive Derating Data
Increasing the carrier frequency above 8kHz (or 5kHz on models 4012 and 4050) will reduce the rated output current as
shown in the table below and Figure 14.
Model HPV1000-
EMC Filter
[Block]
Main Fuse [Bussmann] Dynamic Braking Resistor [Cressall]
4009-BA-N02 FB-40014A FWH-90B
DBR-600-32-E (Geared)
DBR - 1500-32-E (Gearless)
4015-BA-N02
FB-40025A
FWH-80B
DBR-600-32-E (Geared)
DBR - 1500-32-E (Gearless)
4018-BA-N02 FWH-100B
DBR-1500-32-E (Geared)
DBR - 3000-32-E (Gearless)
4024-BA-N02
FB-40044A
FWH-125B
DBR-1500-32-E (Geared)
DBR - 3000-32-E (Gearless)
4031-BA-N024 FWH-200B
DBR-3000-20-E (Geared)
DBR - 4500-20-E (Gearless)
4039-BA-N02
FB-40060A
FWH-250A
DBR-3000-20-E (Geared)
DBR - 4500-20-E (Gearless)
4045-BA-N02
DBR-3000-20-E (Geared)
DBR - 6000-20-E (Gearless)
4060-BA-N02 FB-40072A
DBR-4500-20-E (Geared)
DBR - 6000-20-E (Gearless)
4075-BA-N02
FB-40105A
DBR-4500-13-E (Geared)
DBR - 8000-13-E (Gearless)
4091-BA-N02
DBR-4500-13-E (Geared)
DBR - 8000-13-E (Gearless)
4112-CA-N02
FB-40170A
FWH-350A
DBR-6000-8-E (Geared)
DBR - 12000-8-E (Gearless)
4150-CA-N02 FWH-400A
DBR-8000-8-E (Geared)
DBR - 12000-8-E (Gearless)
Drive Model Number
Continuous Output Current Rating (A)
2kHz 5kHz 8kHz 10kHz 15kHz
HPV1000-4009-BA-N02 9.2 - 9.2 - 5.5
HPV1000-4015-BA-N02 14.8 - 14.8 - 8.9
HPV1000-4018-BA-N02 18 - 18 - 10.8
HPV1000-4024-BA-N02 24 - 24 - 14.4
HPV1000-4031-BA-N02 31 - 31 - 18.6
HPV1000-4039-BA-N02 39 - 39 - 23.4
HPV1000-4045-BA-N02 45 - 45 - 27
HPV1000-4060-BA-N02 60 - 60 - 36
HPV1000-4075-BA-N02 75 - 75 - 45
HPV1000-4091-BA-N02 91 - 91 - 55
HPV1000-4112-CA-N02 112 112 - 78 -
HPV1000-4150-CA-N02 150 150 - 105 -
