4 Keypad Operation
MAGNETEK HPV1000 AC Elevator Drive Technical Manual 13
Feedback Mode Selection
When the drive is first powered up, the appropriate control modes must be selected using BASICS (U8) menu to match
the application. Note that Closed Loop Vector modes require encoder feedback cards. The table below indicates possible
control modes depending on the motor type and shows the required encoder feedback card.
Machine Type Control Mode U8 Setting Encoder Option Card
Induction motor without encoder
V/f Control Open Loop No card required
Open Loop Vector Control Open Loop No card required
Induction motor with incremental encoder Closed Loop Vector Control Closed Loop PG-B3 / PG-X3
Permanent magnet motor with EnDat 2.1/01,
EnDat 2.2/01, EnDat 2.2/22 encoder or Hiperface
encoder
Closed Loop Vector Control for PM motors PM PG-F3
Permanent magnet motor with ERN1387 encoder Closed Loop Vector Control for PM motors PM PG-E3
