5 Programming
MAGNETEK HPV1000 AC Elevator Drive Technical Manual 27
Utility Menu Parameters
Submenus Parameter Name Description
U1 Password
The password allows the user to restrict a select few parameters from being
viewed and accessed without the correct 4 digit password. The value shown in
the “Enter Password” screen as shown below will display the last value that was
entered as a possible password.
If the displayed password does not match the drive’s valid password, the drive
will continue to hide and restrict parameters. The currently set password can be
revealed if the following is done. While in the sub-menu U1 Password with
“Enter Password” on the display, press and hold the “F2” key while hitting the up
directional arrow. If done successfully, the following display below will appear
with the password.
While in the “Select Password” sub-menu, the user can either leave the password
the same, change the password by pressing the “ENTER” key, or resetting the
password back to default of 0 by pressing the “F2” key for reset. After any of the
above is done, press the “ESC” key to go back into the main menu.
U2 Modified Const Lists all parameters that have been edited or changed from default settings
U3 Units Selection
Sets the units that are used and displayed in the drive. The following options can
be selected:
• Contract: m/s
• r/min
•User Units
• 0.0001
• 0.01Hz
• Contract:fpm
U5 Factory Dflts
Initialize all the drive parameters back to default settings. NOTE: the default
settings depends on the setting of Control Method (U8) and Inverter Model #
(U6). The following options can be selected:
• No Initialize - The drive will not initialize the parameters to default settings
• Term -> Cntrl Int - The drive will transfer all the parameter settings from the
terminal board to the control board. Should only need to be done if a new
control board was installed
• Factory Default - The drive will initialize all the parameters to factory default
settings.
U6 Drive Info
Displays and adjusts the drive’s hardware and software configuration and
revisions.
• SW No. (Flash) - Displays the drive software
• SW No. (ROM) - Displays the drive gate firing software
• Drive Firm Ver - Displays the drive software version
• Drive Model - Selects the drive rating
• Operator Firm - Displays the operator software revision
U7 Language Select
Selects different languages. The following options can be selected:
• English
U8 Basics
The control method determines the type of AC motor that will be connected to
the drive and the type of motor control that will be applied to the attached motor.
The following options can be selected:
• V/f Control - The drive will spin an induction motor with no vector control or
no feedback
• Closed Loop Vect - The drive will spin an induction motor with vector control
using an encoder feedback.
• Open Loop Vector - The drive will spin an induction motor with vector control
using no encoder feedback.
• PM - The drive will control a permanent magnet motor with closed loop control
using encoder feedback.
U9 Autotune
Allows the drive to perform autotune on the motor connected to the drive. Refer
to Open-Loop Startup on page 32
.
