5 Programming
26 MAGNETEK HPV1000 AC Elevator Drive Technical Manual
Table 13 C5 Analog Inputs
Table 14 Analog Input Choices
C5 Parameter Name Description
Default
Analog A1 Select Analouge Input A1 Function Select Not Used
Analog A1 Gain Sets the gain level of the input value when 10 V is applied at terminal A1. 100.0
Analog A1 Bias Sets the level of the input value when 0 V is applied at terminal A1 0.0
Analog A1 Offset Applies an offset to analog input A1. Can be used for zero adjustment of the analog input. 0000
Analog A1 Level Sets the required working range of analog input A1 -10 ~ +10VDC
Analog A2 Select Analouge Input A2 Function Select Not Used
Analog A2 Gain Sets the gain level of the input value when 10 V is applied at terminal A2. 100.0
Analog A2 Bias Sets the level of the input value when 0 V is applied at terminal A2. 0.0
Analog A2 Offset Applies an offset to analog input A2. Can be used for zero adjustment of the analog input. 0000
Analog A2 Level Sets the required working range of analog input A2 -10 ~ +10VDC
Analog In Filter Sets a primary delay filter time constant for terminals A1 and A2. Used for noise filtering. 0.03
C5 Choice Description
Motor PTC
Motor Thermistor Input
Declares a Motor OH Alarm at 1.18v
Declares a Motor OH Fault at 2.293v
Not Used Input disabled
Speed Command
Used as the primary external speed reference when the drives speed profile is dictated by an
external speed profile generator within the control system.
Pre-Torque
Load cell input when Trq Comp Type (C1) is configured to Pre-Torque or Torque Feed Forward
when Trq Comp Type (C1) is configured to Feed Forward.
