8 Appendix
68 MAGNETEK HPV1000 AC Elevator Drive Technical Manual
Note: Use crimp insulated terminals or insulated tubing for wiring these connections. Wires should have a continuous maximum
allowable temperature of 75°C 600 V UL approved vinyl sheathed insulation. Ambient temperature should not exceed 40°C.
4045
<4>
R/L1, S/L2,
T/L3
16 10 to 16 14 14 4 6 to 4
M8
9 to 11
(79.7 to 97.4)
U/T1, V/T2,
W/T3
16 10 to 16 14 14 4 6 to 4
–, +1 – 16 to 35 22 14 to 38 – 6 to 1
B1, B2 – 10 to 16 14 8 to 14 – 8 to 4
16 10 to 16 8 8 to 14 6 8 to 6
4060
<4>
R/L1, S/L2,
T/L3
16 16 to 25 22 14 to 22 3 4 to 3
M8
9 to 11
(79.7 to 97.4)
U/T1, V/T2,
W/T3
25 16 to 25 22 14 to 22 3 4 to 3
–, +1 – 25 to 35 30 22 to 38 – 4 to 1
B1, B2 – 16 to 25 14 14 to 22 – 6 to 3
16 16 to 25 14 14 to 22 6 6
4075
<4>
R/L1, S/L2,
T/L3
25 16 to 50 30 22 to 60 2 3 to 1/0
M8
9 to 11
(79.7 to 97.4)
U/T1, V/T2,
W/T3
25 25 to 50 30 22 to 60 2 3 to 1/0
–, +1 – 25 to 50 38 30 to 60 – 3 to 1/0
+3 – 16 to 50 22 14 to 60 – 6 to 1/0
16 16 to 25 22 14 to 22 4 6 to 4
4091
<4>
R/L1, S/L2,
T/L3
35 25 to 50 38 30 to 60 1/0 2 to 1/0
M8
9 to 11
(79.7 to 97.4)
U/T1, V/T2,
W/T3
35 25 to 50 38 30 to 60 1 2 to 1/0
–, +1 – 25 to 50 60 30 to 60 – 3 to 1/0
+3 – 25 to 50 30 22 to 60 – 4 to 1/0
16 16 to 25 22 14 to 22 4 6 to 4
4112
<4>
R/L1, S/L2,
T/L3
50 35 to 95 60 38 to 100 3/0 1/0 to 4/0
M10
18 to 23
(159 to 204)
U/T1, V/T2,
W/T3
50 35 to 95 60 60 to 100 2/0 1/0 to 4/0
–, +1 – 50 to 95 100 60 to 100 – 1/0 to 4/0
+3 – 25 to 95 50 30 to 100 – 3 to 4/0
25 25 22 22 4 4
4150
<4>
R/L1, S/L2,
T/L3
70 50 to 95 80 60 to 100 4/0 3/0 to 4/0
M10
18 to 23
(159 to 204)
U/T1, V/T2,
W/T3
70 70 to 95 80 80 to 100 4/0 3/0 to 4/0
–, +1 – 35 to 95 50 × 2P 50 to 100 – 1 to 4/0
+3 – 50 to 95 60 50 to 100 – 1/0 to 4/0
35 25 to 35 22 22 to 30 4 4 to 2
<1> Gauges listed here are for use in Europe and China.
<2> Gauges listed here are for use in Asia except for China.
<3> Gauges listed here are for use in the United States.
<4> Drive models HPV100-4045 to 4150 require the use of closed-loop crimp terminals for UL/cUL compliance. Use only the tools recommended
by the terminal manufacturer for crimping.
Model
HPV1000
-
Terminal
For Europe and China <1> For Asia <2> For U.S.A <3>
Screw
Size
Tightening
Torque
N·m (lb.in.)
Recommended
Gauge
mm
2
Applicable
Gauge
mm
2
Recommended
Gauge
mm
2
Applicable
Gauge
mm
2
Recommended
Gauge
AWG, kcmil
Applicable
Gauge
AWG, kcmil
