Flex 4EX2 / 6EX2 MRX CE Instruction Manual
November 2018
Page 13 of 44
3.1.2 6EX2 External Illustration
1. STOP Button 7. Pushbutton 4 (PB4)
2. Power Key Switch 8. Pushbutton 5 (PB5)
3. Status LED Indicator 9. Pushbutton 6 (PB6)
4. Pushbutton 1 (PB1) 10. Future Feature
5. Pushbutton 2 (PB2) 11. Battery Cover Screw
6. Pushbutton 3 (PB3) 12. Lanyard and Waist Belt Attachment
Slot
