Magnetek Flex 4EX2 - System Channels Table

Flex 4EX2 / 6EX2 MRX CE Instruction Manual
November 2018
Page 33 of 44
4.2.6 System Channels Table
NOTE: Channel unassigned is represented by “000000” dipswitch setting. See Section 4.1.2
on page 18, part A, unassigned channel scheme.
Ch.
Dipswitch
Setting
Channel
Frequency
(MHz)
CH
Dipswitch
Setting
Channel
Frequency
(MHz)
01 000001 433.050 32 100000 434.600
02 000010 433.100 33 100001 434.650
03 000011 433.150 34 100010 434.700
04 000100 433.200 35 100011 434.750
05 000101 433.250 36 100100 434.800
06 000110 433.300 37 100101 434.850
07 000111 433.350 38 100110 434.900
08 001000 433.400 39 100111 434.950
09 001001 433.450 40 101000 435.000
10 001010 433.500 41 101001 435.050
11 001011 433.550 42 101010 435.100
12 001100 433.600 43 101011 435.150
13 001101 433.650 44 101100 435.200
14 001110 433.700 45 101101 435.250
15 001111 433.750 46 101110 435.300
16 010000 433.800 47 101111 435.350
17 010001 433.850 48 110000 435.400
18 010010 433.900 49 110001 435.450
19 010011 433.950 50 110010 435.500
20 010100 434.000 51 110011 435.550
21 010101 434.050 52 110100 435.600
22 010110 434.100 53 110101 435.650
23 010111 434.150 54 110110 435.700
24 011000 434.200 55 110111 435.750
25 011001 434.250 56 111000 435.800
26 011010 434.300 57 111001 435.850
27 011011 434.350 58 111010 435.900
28 011100 434.400 59 111011 435.950
29 011101 434.450 60 111100 436.000
30 011110 434.500 61 111101 436.050
31 011111 434.550 62 111110 436.100
