Flex 4EX2 / 6EX2 MRX CE Instruction Manual
November 2018
Page 38 of 44
With Optional Removable Mounting Bracket
1. Drill two holes on the control panel, wall or location where the receiver is to be installed.
2. Slide down the receiver along the guided track to secure the receiver to the mounting
bracket.
3. Remove the receiver by pressing down the bracket release and pull the receiver upward
until it clears the guided track.
3
9
m
m
Ő
48mmį
