3 XLTX TRANSMITTER STANDARD CONFIGURATION AND OPERATION
WARNING
BEFORE OPERATING THE TRANSMITTER FAMILIARIZE YOURSELF WITH ALL SAFETY
INFORMATION IN THIS MANUAL, THE CORRESPONDING RECEIVER SYSTEM MANUAL,
APPROPRIATE MANUAL SUPPLEMENTS AND ANY OTHER LOCAL, STATE, OR FEDERAL RULES OR
REGULATIONS ALREADY IN EXISTENCE. FAILURE TO FOLLOW THIS WARNING COULD RESULT IN
SERIOUS INJURY OR DEATH AND DAMAGE TO EQUIPMENT.
Figure 1: Typical XLTX with Maximum Number of Paddles and Auxiliary Switches
