Engineered XLTX Transmitter Instruction Manual
December 2016
Page 46 of 49
8 GENERAL TROUBLESHOOTING
Problem Error on display Reason
Transmitter shuts
down during
normal operation
Off Activated Unit turned off by the operator.
Machine Stop Machine stop pressed by the operator.
Inactivity Timeout
No input has been activated on the transmitter
for the period of time set for the inactivity timer.
Low Battery Transmitter battery is too low.
Drop Detected
A drop of the transmitter has been detected
where it has struck an object.
Long Drop Detected
A free fall drop of the transmitter has been
detected.
TILT
Tilt detection in the transmitter is enabled and
the angle of the tilt is beyond the acceptable
range.
Key Switch Power Off
The transmitter key switch input has been
turned off.
Transmitter shuts
down during
initialization
On/Off Switch FAIL
An error has been detected with the
Off/On/Start switch during startup. Check the
connection between the switch and the board.
Estop FAIL
An error has been detected with the Estop
switch during startup. Check the connection
between the switch and the board.
Motion X failed
An error has been detected with Motion X
during startup where it is not centered. Return
Motion X to the center position and cycle power
to the transmitter. Refer to the system drawings
to determine the location of the switch.
Motion X dir failed
An error has been detected with Motion X
during startup. Check the connection between
the input and the board. Refer to the system
drawings to determine the location of the
switch.
XX failed
An error has been detected with Toggle XX
during startup. Check the connection between
the input and the board. Refer to the system
drawings to determine the location of the
switch.
Temp Error (X)
The transmitter temperature is out of range.
Ensure that the temperature of the transmitter
is between -40° and +40°C.
