Engineered XLTX Transmitter Instruction Manual
December 2016
Page 16 of 49
3.2.1 Turning On the Transmitter (with Standard Status LED Indicator(s))
3.2.1.1 Transmitters Equipped with Separate Power/Status and Battery LED Indicators
First, the Machine Stop switch must be in the raised position (pulled out). Next, push the OFF-
ON-START toggle switch to the ‘ON’ position and release it once the Power/Status LED lights up
as a solid green color. Following the Power/Status LED turning on and illuminating, the unit will
perform a routine initialization.
During initialization, the XLTX scans for any switches or motions that may be on during power up.
If any switches or motions are on, the failure will be displayed as a solid red Battery LED, and
then the XLTX will power itself down.
After a successful initialization, the XLTX will enter normal operation mode and display the normal
operating status LED indications. See Section 3.6 for more information on the normal operation
mode with standard status LED.
3.2.1.2 Transmitters Equipped with Single Status/Battery LED Indicator
First, the Machine Stop switch must be in the raised position (pulled out). Next, push the OFF-
ON-START toggle switch to the START position and release it immediately. The unit will perform
a routine initialization.
During initialization, the XLTX scans for any switches or motions that may be on during power up.
If any switches or motions are on, the failure will power the XLTX down.
NOTE: There will be no LED indication of the failure on the Single LED equipped transmitters. If
the Battery Status LED does not go into slow blinking mode as detailed in Section 3.6 after 15
seconds, reboot the transmitter by turning the OFF the transmitter and then turning the
transmitter back ON.
After a successful initialization, the XLTX will enter normal operation mode and display the normal
operating status LED indications. See Section 3.6 for more information on the normal operation
mode with standard status LED.
3.2.2 Turning On the Transmitter (with Graphic User Interface Screen)
First, the Machine Stop switch must be in the raised position (pulled out). Next, push the OFF-
ON-START toggle switch into the ON position and the Magnetek logo appears on the LCD
screen. Following the logo screen, the unit will perform a routine initialization.
During initialization, the XLTX scans for any switches or motions that may be on during power up.
If any switches or motions are on, the failure will be displayed on the screen, and then the XLTX
will power itself down.
After a successful initialization, the XLTX will enter the Normal Operation Mode and display the
normal operating screen. See Section 3.7 for more information on the Normal Operation Mode.
NOTE: Holding the OFF-ON-START toggle in the START position during start-up for more than 5
seconds will put the device into Setup Mode. For normal use release the START toggle once the
Magnetek logo appears. See Section 4 for more information on the Setup Mode.
3.2.3 Pulling In the Machine Stop Relay
Once the XLTX has been turned on (as described in Section 3.2.1 or 3.2.2) and in the Normal
Operating Mode, the Machine Stop relay in the receiver can be pulled in by pushing the OFF-ON-
START toggle switch to the START position and then releasing.
