Engineered XLTX Transmitter Instruction Manual
December 2016
Page 23 of 49
the IR configuration receiver function will not be used unless the memory override dip switch is
set to ON. When the RF channel from memory override is NOT enabled, the dip switch positions
set the RF channel used by the transmitter.
NOTE: The transmitters equipped with the graphic user interface will read channel settings from
memory and will not respond to dip switch changes for the channel setup. Only the dip switches
for the battery life indication are functional on graphic user interface equipped transmitters.
4.1.3 IR Configuration Receiver
The IR Cfg Recv function allows the transmitter to link to a compatible receiver by using IR
(contact the factory to determine if your receiver is compatible) and automatically set up the
channel and access code to match the linked compatible receiver.
NOTE: If using the IR configuration receiver function on transmitters NOT equipped with the
graphic user interface, the channel settings will read from the dip switch positions and not from
memory when the channel from memory override function is not enabled. The RF channel set by
the IR configuration receiver function will not be used unless the memory override dip switch is
set to ON. When the RF channel from memory override is NOT enabled, the dip switch positions
set the RF channel used by the transmitter.
4.1.3.1 IR Configuration Receiver on Transmitters Equipped with Separate Power/Status
and Battery LED Indicators
To utilize the IR configuration receiver function and link to a compatible receiver, push the OFF-
ON-Start toggle to the Start position and hold for more than 5 seconds. When the transmitter
successfully enters the IR configuration mode, the Power/Status and Battery LED(s) will blink
alternately continuously. After the LEDs are blinking alternately, point the IR window of the
transmitter at the desired receiver to control and momentarily press the OFF-ON-Start toggle to
the Start position and release.
If the link is successful, the LEDs will stop blinking and the transmitter will shut down. The new
settings obtained from the IR configuration function will take effect upon the next power cycle of
the transmitter.
If the link is unsuccessful with a compatible receiver, the Power/Status and Battery LED(s) will
continue to blink alternately.
To cancel the IR configuration receiver without a successful link, move the OFF-ON-Start toggle
to the OFF position.
4.1.3.2 IR Configuration Receiver on Transmitters Equipped with Single Status/Battery
LED Indicator
To utilize the IR configuration receiver function and link to a compatible receiver, push the OFF-
ON-Start toggle to the Start position and hold for more than 5 seconds. When the transmitter
successfully enters the IR configuration mode, the Status/Battery LED will blink continuously.
After the LED is blinking, point the IR window of the transmitter at the desired receiver to control
and momentarily press the OFF-ON-Start toggle to the Start position and release.
If the link is successful, the LED will stop blinking and the transmitter will shut down. The new
settings obtained from the IR configuration function will take effect upon the next power cycle of
the transmitter.
If the link is unsuccessful with a compatible receiver, the Status/Battery LED will continue to blink.
