8.26.1 Front Courtesy/Map Reading (if equipped)
A
Map Reading Lamp (LH)
B1 Permanent ON
B
Roof Lamp
B2 Permanent OFF
C
Map Reading Lamp (RH)
B3
Door/Auto Mode
The front courtesy lamp is located in the roof console above the
front seats. The courtesy lamp can be switched on using the middle
switch (B) on the lamp.
The right/left map reading lamps for the driver/front passenger
are located adjacent to the courtesy lamp and can be individually
switched ON/OFF by the map reading lamp switches (A & C)
Do not leave the courtesy/map reading lamp in permanent ON
mode. This will drain your vehicle battery.
8.26.2 Front Courtesy Lamp — Auto Mode Operation
This is applicable to front row courtesy lamp only. The courtesy
lamp switch (A) has three operation modes to choose from;
B1. The courtesy lamp remains permanently ON in this position
irrespective of the door open status
B2. The courtesy lamp remains permanently OFF in this position
B3. The courtesy lamp remains in AUTO mode in this position. The
operation of the courtesy lamp in Auto mode is as follows;
• Courtesy lamp switches ON, dims and goes OFF after a preset
delay once RKE unlock is performed
• Courtesy lamp switches ON when any of the doors is/are open
• Courtesy lamps dim and go OFF after a preset delay upon closing
of all doors during IGN OFF condition
• Courtesy lamps dim and go OFF immediately on RKE lock or
manual key lock after all doors are closed
• If any of the doors are not closed properly, then the courtesy
lamps switch OFF automatically after a preset duration (during
IGN off) or once the vehicle speed > 20 kmph
• Courtesy lamps go OFF with ignition ON and all doors closed
properly
