© Copyright Mahindra & Mahindra Ltd. 012016
8-19
8.28 Windshield Wipers
8.28.1 Wiper Control Stalk
The wipe/wash function can be activated only when the ignition is in
“IGN” position.
A
Flick Wipe (MIST)
B Off
C
Intermittent (INT)
D
Low Speed (LO)
E
High Speed (HI)
8.28.2 Wiper Off
The wipe function is OFF when the wipe control stalk is in neutral
position (B).
8.28.3 Flick-Wipe (Mist)
Push the wipe control stalk to position A for a flick-wipe, hold to
operate the wipe continuously (simultaneously lift the wiper stalk
towards the steering wheel to operate the wash). The stalk
automatically comes back to position B when released.
8.28.4 Intermittent (INT) Mode
Intermittent (INT) wiping is selected when the wipe control stalk is
pushed down to position C. In the INT mode, the wiper operates on
preset intervals of 4 sec.
The delay between each wipe can be programmed from 1 to 60
sec according to the rain by the user.
Programming of the INT delay time is as follows;
• Turn the wiper stalk to position C, wiper will start wiping
• Turn the wiper stalk to OFF position, before wiper starts second
wipe
• Turn the wiper stalk to position C again after the required delay
and the same delay will be programmed
• On keeping wiper ON position C, the wiper will wipe again with the
programmed delay
FEATURES AND CONTROL
