© Copyright Mahindra & Mahindra Ltd. 012016
8-27
8.31 Instrument Cluster - Type 1
H G F
W12D13
A
E
DC
B
A
Tachometer / RPM Gauge
E
Speedometer
B
Temperature Gauge
F Mode Button
C
Trip Meter
G Odometer
D
Fuel Gauge
H Set Button
FEATURES AND CONTROL
