8.35 Warning Lamps in the Instrument Cluster
8.35.1 Malfunction (OBD) Lamp
The Malfunction (OBD) Lamp illuminates when the
ignition is switched ON and remains ON till the engine
has started indicating normal status. If the lamp
remains ON, it indicates a potential engine malfunction.
There may be a malfunction in:
• The fuel management system
• The emission control system
• Systems which affect emissions
Such malfunctions may result in excessive emissions. Contact an
Authorized Mahindra Dealer immediately.
8.35.2 Check Engine Lamp
The check engine lamp illuminates when the ignition
is switched ON and goes out in 3 seconds indicating
normal status. The lamp blinks or illuminates
continuously if there is a fault in the engine management system.
Contact the nearest Mahindra Dealer for the necessary repairs.
8.35.3 Security Lamp
Once the ignition is turned OFF, the security lamp will
blink at a fast rate frequency indicating the vehicle is
secured against unauthorized start of engine. When
the vehicle is locked using RKE, security lamp will blink at a slow rate
frequency which will indicate that antitheft system is armed and
unauthorized door entry to the vehicle will trigger alarm.
At ignition ON, the security lamp blinking continuously indicates a
malfunction in the engine immobilizer system. Contact an
Authorized Mahindra Dealer immediately.
8.35.4 Parking Brake/Low Brake Fluid/EBD Warning
Lamp (if equipped)
The lamp illuminates when the parking brake is
engaged or when the brake fluid level in the reservoir
is low or when EBD (if equipped) failure is detected. If
the lamp illuminates while driving, do the following:
• Check if the parking brake is engaged. If yes, disengage it
• Check if the brake fluid level is low. If yes, top-up brake fluid (DOT
4) to the required level
If the brake lamp still continues to illuminate, immediately get the
vehicle checked at an Authorized Mahindra Dealer.
