© Copyright Mahindra & Mahindra Ltd. 012016
8-1
8 FEATURES AND CONTROL
8.1 Power Windows
000000000000000000000000000000
B
A C
E D
W12H01
A
Front Passenger Window
Switch
D
Power Window Lock
Switch (Child Safety)
B
Driver Door Window
Switch
E Rear LH Window Switch
C Rear RH Window Switch
The quadruple switch controls the window winding functions of all
the doors of the vehicle. It also houses a child safety switch that
enables/disables the power window operation of both the rear
doors when operated independently from the respective door.
Power windows can be operated only when the ignition is “IGN”
position. The quadruple power window switch is located on the
driver door trim / floor console depending on the variant.
Passengers can also raise or lower their respective window glasses
individually by the separate switches provided on each of the door
trim pads.
000000000000000000000000000000
W12H02
FEATURES AND CONTROL
