4-1
4 INSTRUMENT CLUSTER OVERVIEW
4.1 Instrument Cluster - Type 1
H G F
W12D13
A
E
DC
B
A
Tachometer / RPM Gauge
E
Speedometer
B
Temperature Gauge
F Mode Button
C
Trip Meter
G Odometer
D
Fuel Gauge
H Set Button
