© Copyright Mahindra & Mahindra Ltd. 012016
10-3
10.3 Center/Side Vents
A
Adjustable Louvers
B
Thumb Wheel (Open/Close)
Two center vents are located above the audio system. The two side
vents are located one each at the left and right extreme ends of the
instrument panel. Both the center and side vents provide air flow to
the front seat passengers.
Rotate the thumb wheel (B) up to open or down to close the air
vent. Direct air to the desired direction by the adjusting louvers (A)
left/right.
Rotate the thumb wheel right to open or left to close the air vent.
Direct air to the desired direction by the adjusting louvers left/right.
10.4 Second Row Floor Vents
Two vents for the second row are provided at the rear of the floor
console. The vents have adjustable louvers (A) to direct the air flow
and thumb wheels (B) for vents open/close operations.
HEATING, VENTILATION AND AIR-CONDITIONING SYSTEM (HVAC)
