10-4
© Copyright Mahindra & Mahindra Ltd.012016
W12J04
10.5 HVAC Controls
A/C LO A/C HI
A B C
F E D
W12J05
MANUAL
Auto Climate Control
A
B
D
F H
G
C
W12J24
A Air Distribution Control E AC Low ON
B
Blower Speed Control
F
Air Re-circulation
Switch
C
Temperature Control
G
Blower ON/OFF
D
AC High ON / AC ON
(Auto Climate Control)
H
In-Car Temperature
Sensor (Do Not Touch)
HEATING, VENTILATION AND AIR-CONDITIONING SYSTEM (HVAC)
