© Copyright Mahindra & Mahindra Ltd. 012016
10-11
• The air conditioner should be operated at least for ten
minutes once every fortnight, even during winter months.
This allows the AC system components to get lubricated
periodically and ensures optimum system performance
In the manual HVAC system, the AC HI function has a lower
temperature cut-off than the AC LO function.
• For hot weather conditions or for rapid cooling, it is
recommended to use AC HI. Switch over to AC LO once the
cabin is cooled considerably
• For cold or normal weather conditions, it is recommended to
use AC LO
The following steps outline the procedure to switch ON the AC;
1. Adjust the blower speed as required.
2. Select the air distribution mode as desired.
3. Select the air re-circulation mode if required.
4. Press the AC HI/LO button (manual) or AC button (Auto
Climate Control) to turn ON the AC.
5. Adjust the temperature control dial as per the temperature
requirement.
Your vehicle is equipped with an HVAC filter. If the AC
performance is considerably low, it is recommended have the
HVAC filter checked at the nearest Mahindra Dealer.
10.13 Rapid Cabin Cooling
For rapid cooling of the cabin, the following AC settings are
recommended:
1. Make sure that all the windows are fully closed
2. Set the blower to maximum speed
3. Fully open the vents and adjust louvers to direct air toward
face
4. Set the air distribution control to face mode
5. Set air intake control to recirculation mode
6. Turn the air conditioner ON in AC HI mode (manual HVAC)
7. Set the temperature control knob to the extreme left (coolest)
position
Once the passenger compartment reaches a comfortable
temperature, shift to fresh air, AC LO mode (manual HVAC). Also
blower speed and temperature control knob can be re-adjusted as
desired.
HEATING, VENTILATION AND AIR-CONDITIONING SYSTEM (HVAC)
