8-32
© Copyright Mahindra & Mahindra Ltd.012016
Odometer and trip meter are displayed only when the ignition is
ON. To cycle between trip A & B press and release MODE (B)
button for a second.
8.33.5 Engine Coolant Temperature Gauge
The engine coolant temperature bar graph functions only when the
ignition is switched ON. It indicates the instantaneous engine
coolant temperature. The coolant temperature varies with changes
in weather, load on engine and driving pattern. LCD bar rises from
Cold (C) towards Hot (H).
At normal operating temperature, 4 bars are displayed in the LCD
bar graph. The high engine coolant temperature lamp along with all
8 bars blink when the temperature reaches 110
o
C. And when the
temperature is 119
o
C, the temperature warning lamp and all 8
bars are permanently ON. In such situations switch OFF the AC and
observe any improvements in the temperature gauge. If not, stop
the vehicle and allow the engine to cool down. Check the coolant
level in the coolant reservoir and top-up if required. If the engine is
still overheating, contact your nearest Authorized Mahindra Dealer.
Never remove the degassing tank cap when the engine is hot.
The engine coolant is under pressure and could splash on to
skin/eyes causing severe burns. Wait for the engine to cool
down before adding coolant to the reservoir.
FEATURES AND CONTROL
