11-12
© Copyright Mahindra & Mahindra Ltd.012016
Shifting Between 2H and 4H
Your vehicle is equipped to shift from 2H to 4H mode at any vehicle
speed. To shift from 2H to 4H turn the 4WD selector switch to the
4H position. Once the shifting is complete, the 4WD HIGH lamp in
the instrument cluster illuminates. If the lamp does not come on,
drive straight ahead accelerating or decelerating. If the lamp still
does not come ON, contact your Authorized Mahindra Dealer.
There may be a malfunction in the four wheel drive system.
Never operate the selector switch knob if the wheels are
slipping. Stop the slipping or spinning before operating.
To shift from 4H to 2H, turn the selector switch to the 2H position.
This can be done at any speed and the 4WD HIGH lamp in the
instrument cluster goes off. If the lamp continues to illuminate, drive
straight ahead accelerating or decelerating, or drive forward and
backward in a short distance. If the lamp continues to illuminate,
contact an Authorized Mahindra Dealer. There may be a
malfunction in your four wheel drive system.
To Shift from 4H to 4L
1. Bring the vehicle to a complete stop
2. Brake pedal depressed
3. Shift the gear lever into neutral
4. Turn the four wheel drive selector switch to the 4L position.
The 4WD LOW lamp in the cluster should illuminate and the
4WD HIGH lamp goes OFF. If the 4WD LOW lamp does not
illuminate within 10 sec repeat the above steps again
Note that both the lamps will illuminate during shifting.
STARTING AND DRIVING THE VEHICLE
