Mahindra 2016 Scorpio User Manual

© Copyright Mahindra & Mahindra Ltd. 012016
2-11
Fuse No
Fuse Rating
Circuit
7 20A
Fuel Lid/Anti Pinch
8 5A
Diagnostic
9 10A Park
10 20A
MBFM1/Fuel Pump
11 20A 4WD ECU
12 10A AT
13 10A 4WD Actuator
14 10A
EMS/Immobilizer
15 5A TPS
16 5A Crank
17 10A
Reverse/RPAS IGN
18 10A
MBFM/IC/FATC/IS
19 5A ABS
20 10A
Airbag
21 15A
Front Wiper
22 10A
Rear Wiper
23 5A
MBFM/FATC
24 5A
Audio Key IN
25
Spare
26 10A ORVM
27 15A
P/O Front
28 15A
P/O Rear
29
Spare
30 40A Power Windows
31
Spare
32 40A Blower Motor
33
Spare
Fuse No
Fuse Rating
Circuit
34
Spare
35
Spare
36
Spare
37
Spare
38
Spare
Relay No
Circuit
39
Wiper HI/LO Relay
40
De-mister Relay
41
Fuel Lid Relay
42
Spare
43
Clutch Start Relay
44
Blower Relay
45
Spare
46
Spare
47
Spare
48
Spare
2.5.3 Battery Mounted Fuse Box
The battery mounted fuse box is connected to the positive terminal
of the battery. Functionality of battery mounted fuse box is to
provide short circuit protection to alternator, power supply to main
engine compartment fuse box & electric cooling fan.
