© Copyright Mahindra & Mahindra Ltd. 012016
2-13
• placed in a pouch behind the 3rd row seat/seat back (for 8 seat
— front facing, 7 seat — captain seat variants)
• under the RH jump seat (for 7/9 seat — side facing variants)
The wheel spanner and jack handle are:
• strapped to the 2nd row seat bottom (for 7/9 seat — side
facing variants)
• strapped to the 3rd row seat bottom (for 8 seat — front facing,
7 seat — captain seat variants)
The jack is located under the co-driver's seat. Rotate the jack
handle to reduce the jack height and lift the jack out.
2.6.2 Spare Wheel Removal
The spare wheel is located below the floor at the rear end of the
vehicle. It is held in place by a securing nut underneath the rear
luggage compartment floor carpet.
GENERAL
