© Copyright Mahindra & Mahindra Ltd. 012016
4-5
Symbol Warning Lamp/Tell Tale Lamp Pre-check Lamp Status Action/Remarks
Parking Brake ON/Brake Fluid
Low Warning Lamp
Yes
Continuously ON
Either one of below conditions:-
1) Park brake might be engaged
2) Brake fluid level might be low
Contact Authorized Mahindra Dealer immediately for
assistance if the lamp is not turning OFF even after checking
the above conditions
Left Turn Indicators No
Slow or Fast Blinking
Indicates left turn lamp is blinking
Slow Blinking: Normal operation
Fast Blinking: One /more left turn lamp bulb has fused. Have
the bulb replaced
Water in Fuel Filter Warning
Lamp
Yes
Continuously ON Indicates water in fuel filter. Drain the water from filter or
contact an Authorized Mahindra Dealer for assistance
Security Lamp
No
Slow or Fast Blinking
Slow Blinking: Vehicle armed and Immobilizer system active
Fast Blinking: Once the ignition is turned OFF, security lamp
will blink at fast rate frequency indicating vehicle is secured
against unauthorized start of engine
Check Engine Lamp
For about 3 sec
Continuously ON or
Blinking
There is a potential malfunction in the engine system, contact
an Authorized Mahindra Dealer immediately
INSTRUMENT CLUSTER OVERVIEW
