© Copyright Mahindra & Mahindra Ltd. 012016
4-7
Symbol Warning Lamp/Tell Tale Lamp Pre-check Lamp Status Action/Remarks
Front Fog Lamp Indicator
No
Continuously ON Indicates front fog lamp is ON
Seat Belt Warning Lamp
No
Continuously ON
Indicates driver seat belt not fastened. If tell tale is not turning
OFF even after fastening the driver seat belt, contact an
Authorized Mahindra Dealer for assistance
Low Fuel Warning Lamp
No
Continuously ON
The fuel level in the fuel tank is low. Re-fuel immediately to a
avoid empty tank
TPMS Warning Lamp
No
Continuously ON or
Blinking
Indicates low tyre pressure or possible malfunction in TPMS.
Refer to the TPMS section in the FEATURES AND CONTROL/
WHEELS AND TIRES chapter for further details
4WD High
No
Continuously ON Indicates transmission is in 4WD High
4WD Low No
Continuously ON
Indicates transmission is in 4WD Low
Malfunction Lamp (OBD)
Continuously ON till
Engine Starts
Continuously ON
There is a potential malfunction related to emission control
system, contact an Authorized Mahindra Dealer immediately
INSTRUMENT CLUSTER OVERVIEW
