© Copyright Mahindra & Mahindra Ltd. 012016
7-3
A Lock B Unlock
Individual doors can be locked/unlocked from inside by the
respective door lock tabs.
Pull the lock tab outwards to unlock or press the tab inwards to lock
that particular door.
Locking the driver door from inside activates the central locking
system (if equipped), thereby locking ALL the doors of the
vehicle. Refer to the ‘Central Locking’ section for further details.
Locking/Unlocking Doors from Outside :
A key hole is provided in the driver door and back door to lock/
unlock the door from outside by using the manual or conventional
key. The key is bi-directional; you can insert it into the key hole in
both directions.
2680
4430
19
75
Lock
Un-lock
W12G07
Locking the driver door from outside activates the central
locking system (if equipped), thereby locking ALL the doors of
the vehicle. Refer to the ‘Central Locking’ section for further
details.
LOCKS AND KEYS
