MP7500 Router Installation Manual Version 1.0
System Installation
Preparations
Tools
Before installation, prepare slotted point screwdriver/cross point
screwdriver, level, ruler or tapeline, and anti-static equipment
Checking Cabinet
Maipu devices are designed according to the dimension of 19-inch
standard cabinet, so they can be installed and fixed normally on 19-inch
standard cabinet.
MP7500 router is 14U high. Before installing MP7500, reserve enough slot
room.
Use the level or tapeline to measure the center distance of the horizontal
installation hole and net horizontal direction installation space of the
cabinet.
Check whether the pallet bracket, floating nut, fixed screw, and baffle
board on the cabinet are complete, which are the standard accessories.
Different cabinets have different dimensions and shapes. Therefore, to add
cabinet accessories, contact the supplier of the cabinet to provide genuine
accessories.
The device must be installed on the pallets or trays (used in pairs) of the
cabinet. Therefore, install the pallets or trays on the cabinet before
installing the device as follows. Use the level to check whether the pallets
or trays are horizontal. If not, adjust the fixed bolt of pallet or tray to
make the pallet or tray horizontal and then fasten it.
