Console port cable connection relation:
RJ45 Signal Direction DB9 Length
1 CTS —> 8
2 DSR —> 6
3 RXD —> 2
4 GND --- 5
5 --- --- ---
6 TXD <— 3
7 DTR <— 4
8 RTS <— 7
--- --- 1
--- --- 9
3m
