MP7500 Router Installation Manual Version 1.0
RM7B-8/16/32CE1/RM7B-8/16/32E1 Cable
CE1/E1 interface of MP7500 is 40-pin jack:
DB40 (pin) Signal BNC Signal Description Length
1 RX1+ Pin RX1+
2 RX1- Screen RX1-
RX1
3 RX2+ Pin RX2+
4 RX2- Screen RX2-
RX2
5 Empty
6 RX3+ Pin RX3+
7 RX3- Screen RX3-
RX3
8 RX4+ Pin RX4+
9 RX4- Screen RX4-
RX4
10 Empty
11 Empty
12 RX5+ Pin RX5+
13 RX5- Screen RX5-
RX5
14 RX6+ Pin RX6+
15 RX6- Screen RX6-
RX6
16 Empty
17 RX7+ Pin RX7+
18 RX7- Screen RX7-
RX7
19 RX8+ Pin RX8+
20 RX8- Screen RX8-
RX8
21 TX1+ Pin TX1+
22 TX1- Screen TX1-
TX1
23 TX2+ Pin TX2+
24 TX2- Screen TX2-
TX2
25 Empty
26 TX3+ Pin TX3+
27 TX3- Screen TX3-
TX3
28 TX4+ Pin TX4+
29 TX4- Screen TX4-
TX4
2M
30 Empty
