CHALLENGERSERIES10‐60KVA  EXPLANATIONSOFLOGGING
AG–SD‐35Rev.No:1Rev.Date:25.09.2013PublicationNo:2 66


98 BatteryTemp. Nor. Batterytemperatureisnormal.
99 OutputSignalON UPSoutputswitchisopened.Loadscanbeenergized.
100 FansActive
Abletocommunicatewiththefancontrolsystem.Onlyfor
UPSsthatcontainthefancontrolsystem.
101 PFCPbusOverVoltage PositiveDCBusovervoltage.
102 PFCNbusOverVoltage NegatifDCBusovervoltage
103 PFCPhL1OverCurrent ShortcircuitprotectionisactivatedforrectifierL1phase.
104 PFCPhL2OverCurrent ShortcircuitprotectionisactivatedforrectifierL2phase.
105 PFCPhL3OverCurrent ShortcircuitprotectionisactivatedforrectifierL3phase.
106 SingleStop
CommandtostopitselfhasbeengiventoUPSwhichis
operatinginparalelmodeseparatelyfromparalelsystem.
107 MasterChanged UPSbecamemasterdeviceinparalelsystem.
108 Par.BusIDCollision
IDvalueofoneormoreUPSisthesameaseachotherin
parallelsystem.
109 OutputOffsetErr.
OneormorephaseofslaveUPS’outputisnotconnectedto
masterUPSinParallelsystems.
110 BypassShortCircuit
Short‐circuitcurrentlimithasbeenexceededinthe
maintenancebypassmode.UPSisshutdown.
111 RMSoutputFailure
Thevalueofoutputvoltageisoutofthelimits.UPSwillbe
shutdown.
112 StopAllUnits Stopallunitscommandwasgivenviafrontpanel.
113 FloatChargeMode
UPSchargemodehasswitchedtothestandbymodeatthe
constantvoltagefromconstantcurrentmode.
114 Pwr.SupplyFault
TheerrorsignalisdetectedonUPSthroughpowersource
circuitdebugger.
115 GeneratorMode
Signalisdetectedfrom"generatormodeinput"ofdry
contactboard.UPSwillswitchto"generatormode".
