Malaguti PHANTOM MAX 250 - Page 106

4
EN
SECT. SUBJECTS PAGE
1 General information 5
1.1 Riding Safety (rider + passenger) 5
1.2 Identification data 6
1.3 Tyres 7
1.4 Fuel tank 8
1.5 Coolant tank 8
1.6 Rear-view mirrors 9
2 Getting to know your vehicle 11
2.1 Technical data 11
2.2 Main components 12
2.3 Helmet compartment 13
2.4 Antitheft hook 13
2.5 Front ticket compartment 14
2.6 Dashboard 15
2.7 Digital dashboard 16
2.7.1 Function selection and warning lights 17
2.7.1.1 Warning lights 18
2.8 Handlebar controls - right handlebar 20
2.9 Handlebar controls - left handlebar 21
2.10 Switch with key 22
2.11 Handlebar lock 22
2.12 Stands 23
2.12.1 Centre stand 23
2.12.2 Side stand 23
3 Operating instructions 25
3.1 Running-in 25
3.2 Checks before use 25
3.3 Electric starting 26
3.4 Cold starting 26
3.5 Starting 26
3.6 Braking 26
3.7 Engine stopping 26
SECT. SUBJECTS PAGE
3.8 Riding suggestions 27
3.9 Standard equipment 27
3.10 Trouble-shooting 27
3.11 Cleaning suggestions 28
3.12 Garaging 28
4 Scheduled maintenance 29
4.1 Maintenance - warnings 29
Version 250cc.: MAINTENANCE TABLE: CHECK COUPONS 30
Version 125cc.: MAINTENANCE TABLE: CHECK COUPONS 31
4.2 Transmission oil (Version 250cc.) 32
Transmission oil (Version 125cc.) 33
4.3 Engine oil (Version 250cc.) 34
Engine oil (Version 125cc.) 36
4.4 Front/rear brake oil 38
4.5 Spark plug 39
4.6 Rear shock absorber adjustment 40
4.7 Table of lubricants 41
5 Unscheduled maintenance 43
5.1 Adjustment of idling speed 43
5.2 Throttle clearance adjustment 43
5.3 Brake lever adjustment 43
5.4 Brakes (front/rear) pads and rotor check (checking for wear) 43
5.5 Coolant 44
6 Electrical equipment 45
6.1 Headlight 45
6.2 Beam adjustment 45
6.3 Dashboard 46
6.4 Tail-lamp 46
6.5 Number plate light 46
6.6 Indicator lights 46
6.7 Fuses 47
6.8 Battery 48
